Bucket Capacities	0.6-1.0 m3 (0.8-1.3 yd3)
Bucket Capacities - General Purpose	0.6 m3 (0.8 yd3)
Bucket Capacities - Light Material	1.0 m3 (1.3 yd3)

ROPS	ISO 3471:2008
FOPS	ISO 3449:2005 Level I

Cab Height	8.25 ft 2510 mm
Ground Clearance	10 in 250 mm
Wheel Base	6.42 ft 1950 mm
Overall Length - With Bucket*	16.17 ft 4936 mm
Reach at Maximum Dump Height*	2.42 ft 729 mm
Dig Depth	8 in 195 mm
Maximum Dump Height*	8 ft 2435 mm
Load Over Height	9.67 ft 2942 mm
Hinge Pin at Maximum Height	10.58 ft 3227 mm
Departure Angle - Degrees	30°
Overall Length - With Forks	17.58 ft 5363 mm
Reach - Ground Level	3.25 ft 979 mm
Maximum Reach	4.92 ft 1486 mm
Fork Depth Above Ground	2 in 40 mm
Fork Height at Maximum Reach	4.67 ft 1421 mm
Maximum Fork Height	10.33 ft 3146 mm
Fork Reach at Maximum Height	2 ft 609 mm
Turning Radius - Over Bucket*	13.42 ft 4086 mm
Turning Radius - Inside Tire**	5.92 ft 1816 mm
Width - Over Bucket*	5.83 ft 1770 mm
Tire Gauge	4.33 ft 1314 mm
Machine Width**	5.58 ft 1708 mm
Articulation Angle	40°
Steering Angle	80°
Dump Angle at Maximum Height	40°
Note (1)	*Vary with bucket size.
Note (2)	**Vary with tire size.
Note (3)	Dimensions listed are based on the machine configured with cab with air conditioning, remote quick coupler, general purpose bucket or 1067 mm (42 in) forks, 75 kg (165 lb) operator, 33 × 15.5-16.5, 12 PR tires, without ride control, without precleaner.

Cab Height	8.25 ft 2510 mm
Ground Clearance	10 in 250 mm
Wheel Base	6.42 ft 1950 mm
Overall Length - With Bucket*	15.75 ft 4790 mm
Reach at Maximum Dump Height*	2.33 ft 720 mm
Dig Depth	6 in 163 mm
Maximum Dump Height*	7.5 ft 2292 mm
Load Over Height	9.17 ft 2801 mm
Hinge Pin at Maximum Height	10.08 ft 3086 mm
Departure Angle - Degrees	30°
Overall Length - With Forks	17.08 ft 5205 mm
Reach - Ground Level	2.67 ft 821 mm
Maximum Reach	4.5 ft 1368 mm
Fork Depth Above Ground	2 in 40 mm
Fork Height at Maximum Reach	4.67 ft 1421 mm
Maximum Fork Height	9.83 ft 3005 mm
Fork Reach at Maximum Height	2 ft 600 mm
Turning Radius - Over Bucket*	13.17 ft 4007 mm
Turning Radius - Inside Tire**	5.92 ft 1816 mm
Width - Over Bucket*	5.83 ft 1770 mm
Tire Gauge	4.33 ft 1314 mm
Machine Width**	5.58 ft 1708 mm
Articulation Angle	40°
Steering Angle	80°
Dump Angle at Maximum Height	40°
Note (1)	*Vary with bucket size.
Note (2)	**Vary with tire size.
Note (3)	Dimensions listed are based on the machine configured with cab with air conditioning, remote quick coupler, general purpose bucket or 1067 mm (42 in) forks, 75 kg (165 lb) operator, 33 × 15.5-16.5, 12 PR tires, without ride control, without precleaner.

Maximum Gross Power	42 HP 31 kW
Engine Model	Cat C2.4*
Gross Power	42 HP 31 kW
Net Power - 2,200 rpm - SAE J1349 R-ing	40 HP 30 kW
Net Power - 2,200 rpm - ISO 9249 R-ing	40 HP 30 kW
Bore	3.4 in 87 mm
Stroke	4 in 102 mm
Displacement	147 in² 2.4 l
Note	*Engine meets U.S. EPA Tier 4 Final emission standards.

Main Relief	3481 psi 240 bar
3rd Auxiliary Flow	14 gal/min 52 l/min
Hydraulic Cycle Time - Lower, Float	2.4 s 2.4 s

Hydraulic Cycle Time - Lift	4.4 s 4.4 s
Hydraulic Cycle Time - Dump	0.7 s 0.7 s

Bucket Type	General Purpose
Rated Capacity	0.8 yd³ 0.6 m³
Dump Height	90 in 2290 mm
Maximum Material Density	3169 lb/yd³ 1880 kg/m³
Bucket Width	70 in 1770 mm
Note	Based on ISO 7546:1983 and rated operating loads at full turn and standard linkage.

Bucket Type	Light Material
Rated Capacity	1.3 yd³ 1 m³
Dump Height	85 in 2160 mm
Maximum Material Density	1989 lb/yd³ 1180 kg/m³
Bucket Width	74 in 1880 mm
Note	Based on ISO 7546:1983 and rated operating loads at full turn and standard linkage.

Tire Size	33 × 15.5-16.5, 12 PR
Rated Bucket Capacity	0.8 yd³ 0.6 m³
Breakout Force	6204 lbf 28 kN
Operating Weight	9462 lb 4292 kg
Rated Operating Load at Full Turn - Bucket***	2502 lb 1135 kg
Straight Tipping Load - Bucket***	5975 lb 2710 kg
Full Turn Static Tipping Load - Bucket (ISO 14397-1*)***	5004 lb 2270 kg
Full Turn Static Tipping Load - Bucket (Rigid Tire**)***	5115 lb 2320 kg
Rack Back - Transport Position	51°
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Firm and Level Ground, 500 mm [20 in] Load Center) (80% FTSTL)***	3148 lb 1428 kg
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Rough Terrain, 500 mm [20 in] Load Center) (60% FTSTL)***	2361 lb 1071 kg
Note (1)	*Full compliance to ISO 14397-1 (2007) Sections 1 thru 6, which requires 2% verification be-tween calculation and testing.
Note (2)	**Compliance to ISO 14397-1 (2007) Sections 1 thru 5.
Note (3)	***Manual quick coupler, precleaner hood.
Note (4)	Operating specifications shown are based on machine equipped with enclosed ROPS cab with air conditioning, remote quick coupler, 75 kg (165 lb) operator and general purpose bucket (GP), without ride control, without precleaner unless otherwise noted.

Tire Size	33 × 15.5-16.5, 12 PR
Rated Bucket Capacity	0.8 yd³ 0.6 m³
Breakout Force	6160 lbf 27 kN
Operating Weight	9414 lb 4270 kg
Rated Operating Load at Full Turn - Bucket***	2701 lb 1225 kg
Straight Tipping Load - Bucket***	6415 lb 2910 kg
Full Turn Static Tipping Load - Bucket (ISO 14397-1*)***	5401 lb 2450 kg
Full Turn Static Tipping Load - Bucket (Rigid Tire**)***	5512 lb 2500 kg
Rack Back - Transport Position	51°
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Firm and Level Ground, 500 mm [20 in] Load Center) (80% FTSTL)***	3366 lb 1527 kg
Rated Operating Load at Full Turn - Forks (EN 474-3:2006, Rough Terrain, 500 mm [20 in] Load Center) (60% FTSTL)***	2524 lb 1145 kg
Note (1)	*Full compliance to ISO 14397-1 (2007) Sections 1 thru 6, which requires 2% verification be-tween calculation and testing.
Note (2)	**Compliance to ISO 14397-1 (2007) Sections 1 thru 5.
Note (3)	***Manual quick coupler, precleaner hood.
Note (4)	Operating specifications shown are based on machine equipped with enclosed ROPS cab with air conditioning, remote quick coupler, 75 kg (165 lb) operator and general purpose bucket (GP), without ride control, without precleaner unless otherwise noted.

Cooling System	3 gal (US) 11 l
Fuel Tank	11.4 gal (US) 43 l
Hydraulic System	6.3 gal (US) 24 l
Engine Oil	2.4 gal (US) 9 l

Recyclability

97%

Travel Speed

12.4 mile/h 20 km/h

Operating Weight

9414 lb 4270 kg
